Frame and web running:
1. The frame is made of alloy cast iron with high strength and lower stress. It is casted by resin sand process and treated by vibration aging.
2. Integral type guide roller structure.
3. Assembled modularization in design.
4. Frame thickness 100mm
5. Guide roller Φ100mm (Surface anodic oxidation treatment)
Main parameter:
|
Model |
YTD-4color |
|
Material feeding width |
600mm 800mm 1000mm 1200mm 1400mm |
|
Max Printing Width |
560mm 760mm 960mm 1160mm 1360mm |
|
Colors |
4colors |
|
Material |
Pe.pet.bopp.pvc.nylon.non-woven.breathable film |
|
Thickness of plate |
1.14mm.1.7mm 2.28mm.2.84mm. 3.94mm Customized is available |
|
Printing length |
Standard is 400mm， Customized is available from380-800mm |
|
Maximumprintingspeed |
250m/min |
|
Register precision |
longitudinal registration±0.15mm Transversal registration±0.15mm |
|
Structure type |
Central impression（central drum） |
|
Gear module |
1.5mm |
|
Heating method |
Electricity heating |
|
Max. oven temp. |
Max. 80℃(room temp. 20℃） |
|
Unwinder/rewinder paper |
core 3＂ |
|
Max.unwinder/rewinder dia. |
1000mm |
|
Suitable Ink |
Water based ink / Solvent ink |
