Main parameter:
|
Model |
YTB |
|
Type |
Stack |
|
Standard Machine width |
600mm 800mm 1000mm 1200mm |
|
Material Feeding Width |
200-1600mm, also can customized for more width material |
|
Printing Width |
160-1560mm, also can customized for more width material |
|
Printing Length |
Standard is 400mm，can customized from 300-1000mm |
|
Max Machine Speed |
100- m/min |
|
Printing Speed |
10-80 m/min Equip chamber doctor blade can reach 100m/min |
|
Register precision |
≤0.3mm |
|
Thickness of plate |
1.14mm 1.7mm 2.28mm 2.84mm 3.94mm can customized |
|
Gear |
1.5mm |
|
Transmission |
Synchronous Belt |
|
Heating |
Electricity Heating |
|
Double tape thickness for stick plate |
0.38mm 0.5mm can customized |
Printing sections:
1. plate roller circumference: 300-1000mm, standard less than 400mm
2. print material: resin plate or rubber plate
3. Transmission between printing roller and anilox roller: Helical gears
4. printing chromatography: 360-degree rotation
5. adjustment method: By Manual (Automatic printing after adjust by manual, when start machine, no need register color again, the printing pressure and register all keep the same.)
6. Printing roller lifting system: pneumatic
PRINT SAMPLE:
|
|
|
Pre-Sales One-stop Service * Inquiry and consulting support* Latest industry trends * More fit printing solution * Sample testing support * View our Factory * Suggest layout support |
After-Sales Service * One year warranty * Machine test video before delivery * English Manual, Electric Diagram * Training how to install the machine, training how to use the machine * Engineers available to service machinery overseas |
 |
As per export standard, they will also be treated before delivery against damage and rusting. |
|
|
Package |
As per export standard, they will also be treated before deliver against damage and rusting. |
|
