What should I pay attention to when printing materials?

Date:2023-03-10 09:16:27 click:324

1. Be sure to reserve bleeding lines

Text on the page must be spaced from the cropped edge. 3mm, so as not to be cut when cutting.

2. Twist.

With software such as CoreIDRAW, text must be curvy or framed, otherwise the font will be missing. After the text is curved, please pay attention to whether there is skipping or overlapping between the words or lines. Try not to use the system word, if used will cause the stroke interleaved white nodes. If there are white nodes at the interlacing of strokes, it can be handled with the instruction of shattering.

3. Printing color difference.

The printing color cannot be required by the color printed on the screen or printer. The customer must refer to the percentage of CMYK chromatography to determine the color filling. At the same time, note that the CMYK chromatography produced by different manufacturers is affected by the paper, ink type, printing pressure and other factors, the same color block will be different. The same document in different times of printing, color will be different, printing industry recognized color difference within ±10% is normal

4. Color block use.

Please try not to use the combination of dark color or full plate color. Otherwise, it will be easy to backprint after printing. Pay special attention to any picture, color block or line beyond the production size, should be placed in the picture frame. Do not use white color block cover, so as not to cause trouble when the version.

5. Printing background color.

Shading or backpicture color should not be less than 10% to avoid printing the finished product without rendering.

6. Document format.

Please use the CoreIDRAW9.0 Chinese version of the design of the document, due to the needs of the version, the Macintosh design of the document will be converted to PC format.

7. Thickness of wire frame.

Picture album printing all input or self-drawn graphics, the wire frame thickness should not be less than 0.1mm, otherwise the print will cause line breaking or can not be presented. In addition, the wire frame cannot be set "zoom with image", otherwise the print output will form irregular lines.

8. Accurate frame tailoring.

When the gradient object is placed in the graph frame for precise clipping, it should be converted to a bitmap, because the gradient in the graph frame is rotated after other object groups, and the gradient direction will not rotate together. In addition, any gradient object can not be set "edge width", because the interpretation of the output machine is different, sometimes resulting in gradient edge filling insufficient color.

9. Don't leave cut lines.

There is no need to draw cross lines and cutting lines when the manuscript is completed. Two invisible wire frames can be used to act as the production size and bleeding line of 92x56mm, which is 90x54mm after cutting (that is, 1mm bleeding is reserved on each side). If special dimensions are required, please specify them in the order form and in the uploaded documents.
